深圳湾边贸易公司原装进口美国Gammex 156乳腺模体价格优惠！

厂家：Gammex, Inc.

品名：MammographicAccreditation Phantom Model 156

型号：Gammex 156,   Gammex Model 156

尺寸：

Dimensions

Phantom Body
Material . . . . . . . Acrylic
Phantom Dimensions . . . . . . . 4.5x10.2x10.8 cm (HWD) (1.75x4x4.25 in)

Acrylic ba[x]se . . . . . . . . . . .  . . . 3.3 cm (1.3 in) thick
Cover . . . . . . . . . .  . . . . . . . . . .0.3 cm (0.12 in) thick
Acrylic Disk . . . . . . . . . . . . . . . 4 mm thick x 1 cm diameter
Test ob[x]jects . . . . . . . . . . . . . . .Nylon fibrils (1.56, 1.12, 0.89, 0.75, 0.54 and
0.40 mm nylon fibers)

Simulated microcalcifications.(0.54, 0.40, 0.32, 0.24 and 0.16 mm specks)

Tumor-like masses . . . . . . . . .(2.00, l.00, 0.75, 0.50, 0.25 and 0.16 mm specks)
Included is a film, which is a contact image of the wax insert of your Gammex 156

产品介绍：

The Mammographic Accreditation Phantom Model 156 is
designed to test the performance of a mammographic
system by evaluation of the system’s ability to image
small structures similar to those found clinically. ob[x]jects
within the phantom were designed to simulate micro-calcifications,
fibrous structures in ducts, and tumor-like masses,
small structures that are important in the early detection
of breast cancer. Test ob[x]jects within the phantom
range in size from those that should be visible on any system
to ob[x]jects that will be difficult to see even on the best
mammographic systems.
Storage and Handling
Store the Mammographic Accreditation Phantom Model
156 in a cool dry area avoiding temperature extreme such
as intense heat and direct sunlight, or freezing temperatures.
Impact stress may cause breakage.
3
Product Desc[x]ription
The Mammographic Phantom is made up of a wax block
containing 16 various sets of test ob[x]jects, a 3.3 cm (1.3
